Suitable for sorting and re-inspection of all retrieved terminals, excluding those subject to operational sampling and user-initiated calibration.
Functions
- Integrated function and protocol consistency
- Functional test
- Overall power consumption test of control circuit
- Circuit inspection test
- Encrypted virtual meter conversion test, clock & positioning test, metering function test
- Wiring-free, automatic connection of voltage and current signals
- Automatic image acquisition, intelligent analysis and archiving
Technical Parameters
| Whole Machine Function and Protocol Consistency Testing | |
| Accuracy Class | Class 0.05 |
| Voltage Output and Detection Range | 30 V … 456 V, Output stability ≤ 0.05%/120s |
| Current Output and Detection Range | 25 mA … 25 A, Output stability ≤ 0.05%/120s |
| Phase Output and Detection Range | 0.00° … 359.99° |
| Frequency Output and Detection Range | 45 Hz … 65 Hz |
| Harmonic Output and Detection Range | 2 to 21 times, 40% per time (relative to the fundamental wave) |
| Output Power | Voltage 900 VA, Current 1200 VA |
| Table Bit Position | Up to 8 Epitopes |
| 6MP 1/1.8″ CMOS Gigabit Ethernet Industrial Area Scan Camera | |
| Sensor Type | CMOS, Rolling Shutter |
| Resolution | 3072 × 2048 |
| Pixel Size | 2.4 μm × 2.4 μm |
| Target Surface Size | 1/1.8" |
| Maximum Frame Rate | 19.1 fps @ 3072 × 2048 Mono 8 |
| Pixel Format | Mono 8 / 10 / 10 Packed / 12 / 12 Packed |
